INTEGRATED

REMOTE START

PLATFORMS

OL-RS-BMZ FULLY INTEGRATED REMOTE START SYSTEM FOR BMW MODELS.

RELAY CONNECTOR PROGRAMMING BUTTON: • Fully integrated on-board Dual ol-mdb-all Data Interface
These on-board relays are auto- BLACK 20 PIN CONNECTOR Used to program the OL-RS-VWA (no external bypass required)
configured by the firmware, • BYPASS / DATA INTERFACE I/O firmware to the vehicle and perform
making installation simple. • T-HARNESS system reset when needed. • Full Analog / Digital System
• Omega & Excalibur RF-KIT & LINKR Telematics Ready
• T-Harness REQUIRED - SEE BELOW
• Negative Horn-honk Output
OMEGA RF-KIT / WEBLINK
CONNECTOR (BLACK 4 PIN)
This connector plugs directly into any
Omega Excalibur RF-KIT, and is also
used as the weblink connector to flash
and update the OL-RS-VWA using a PC
with the OL-LOADER or a Weblink Mobile
for iPhone and Android.
UNUSED

INPUT/OUTPUT CONNECTORS LINKR TELETMATICS/ACC CONNECTORS
These connectors are when vehicle in- (BLUE & RED 4 PIN)
formation cannot be provided via data. These Connectors are used to add a Linkr device to provide
This provides the option of using this smart-phone control from anywhere in the world you
system completely analog, expanding have cellular service. They can also be used for any other
vehicle applications into the 1,000s. compatible data driven accessories.

OL-RS-BMZ T-HARNESSES T-HARNESSES BELOW ARE REQUIRED FOR INSTALL

OL-ADS-THR-BM1 OL-ADS-THR-BZ1
BMW/Mini T-harnesses OL-ADS-THR-BZ2
Factory fit installation ‘T’-harness for OL-ADS-THR-BZ3
select BMW/Mini models 2005-2016. OL-ADS-THR-BZ4
Mercedes-Benz T-harnesses
Factory fit installation ‘T’-harness for select
Mercedes-Benz models from 2006-2013 (BZ1),
select Mercedes-Benz models from 2016 and
up (BZ2), select Mercedes-Benz models from
and 2008 and up (BZ3), and select Mercedes-
Benz models 2012-2014 (BZ4).

6 6 VISIT WWW.WIRESHEET.COM FOR THE LATEST VEHICLE COMPATIBILITY!
